- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionREFLECTIONLESS BAND PASS FILTER,
- CategoryRF Filters
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$12.5818
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Frequency:20GHz Center
- Bandwidth:1GHz
- Filter Type:Band Pass
- Ripple:-
- Insertion Loss:6dB
- Mounting Type:Surface Mount
- Package / Case:24-VFQFN Exposed Pad
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height (Max):0.039" (1.00mm)
