PS9587-AX
CEL (California Eastern Laboratories)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 5KV OPEN COLLECTOR 8DIP
- CategoryOptoisolators - Logic Output
- Datasheet PS9587-AX Datasheet
-
ECAD Model
- Share
In Stock: 113
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:NEPOC
- Package:Bulk
- Part Status:Discontinued at Digi-Key
- Number of Channels:1
- Inputs - Side 1/Side 2:1/0
- Voltage - Isolation:5000Vrms
- Common Mode Transient Immunity (Min):15kV/µs
- Input Type:DC
- Output Type:Open Collector
- Current - Output / Channel:25 mA
- Data Rate:10Mbps
- Propagation Delay tpLH / tpHL (Max):75ns, 75ns
- Rise / Fall Time (Typ):20ns, 10ns
- Voltage - Forward (Vf) (Typ):1.65V
- Current - DC Forward (If) (Max):30mA
- Voltage - Supply:4.5V ~ 5.5V
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Through Hole
- Package / Case:8-DIP (0.300", 7.62mm)
- Supplier Device Package:8-DIP
