PS9303L-V E3-AX

Technical Details

• Series:NEPOC
• Package:Tape & Reel (TR)
• Part Status:Discontinued at Digi-Key
• Number of Channels:1
• Inputs - Side 1/Side 2:1/0
• Voltage - Isolation:5000Vrms
• Common Mode Transient Immunity (Min):15kV/µs
• Input Type:DC
• Output Type:Push-Pull, Totem Pole
• Current - Output / Channel:25 mA

• Data Rate:1Mbps
• Propagation Delay tpLH / tpHL (Max):500ns, 550ns
• Rise / Fall Time (Typ):120ns, 90ns
• Voltage - Forward (Vf) (Typ):1.6V
• Current - DC Forward (If) (Max):20mA
• Voltage - Supply:4.5V ~ 20V
• Operating Temperature:-40°C ~ 100°C
• Mounting Type:Surface Mount
• Package / Case:6-SOIC (0.268", 6.80mm Width)
• Supplier Device Package:6-SDIP Gull Wing
