LZ4-00MD09-0000
LED Engin
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED EMITTER RGBW DOMED LENS SMD
- CategoryLED Lighting - Color
- Datasheet LZ4-00MD09-0000 Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$13.67
- 250$8.00224
- 500$7.58106
- 750$7.30028
- 1,250$7.15989
Quote It
Technical Details
- Series:LZ4
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Color:Red, Green, Blue, White - Cool (RGBW)
- Wavelength:624nm Red, 525nm Green, 457nm Blue, 6100K White
- Current - Test:700mA Red, 700mA Green, 700mA Blue, 700mA White
- Voltage - Forward (Vf) (Typ):2.5V Red, 3.6V Green, 3.2V Blue, 3.2V White
- Lumens/Watt @ Current - Test:66 lm/W Red, 63 lm/W Green, 13 lm/W Blue, 85 lm/W White
- Current - Max:1A Red, 1A Green, 1A Blue, 1A White
- Luminous Flux @ Current/Temperature:115lm Red, 160lm Green, 30lm Blue, 190lm White
- Temperature - Test:25°C
- Viewing Angle:95°
- Mounting Type:Surface Mount
- Package / Case:2828 (7070 Metric)
- Supplier Device Package:SMD
- Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
- Height - Seated (Max):0.154" (3.90mm)
