XQEGRN-H2-0000-000000A03

Technical Details

• Series:XLamp® XQ-E
• Package:Tape & Reel (TR)
• Part Status:Active
• Color:Green
• Wavelength:530nm (525nm ~ 535nm)
• Current - Test:350mA
• Voltage - Forward (Vf) (Typ):2.85V
• Lumens/Watt @ Current - Test:81 lm/W
• Current - Max:1A

• Luminous Flux @ Current/Temperature:91lm (87lm ~ 94lm)
• Temperature - Test:25°C
• Viewing Angle:130°
• Mounting Type:Surface Mount
• Package / Case:0606 (1616 Metric)
• Supplier Device Package:SMD
• Size / Dimension:0.063" L x 0.063" W (1.60mm x 1.60mm)
• Height - Seated (Max):0.068" (1.73mm)
