XPCGRN-L1-0000-00902
Cree
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED XLAMP XP-C GREEN SMD
- CategoryLED Lighting - Color
- Datasheet XPCGRN-L1-0000-00902 Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$1.21001
- 1,000$1.21001
Quote It
Technical Details
- Series:XLamp® XP-C
- Package:Tape & Reel (TR)
- Part Status:Active
- Color:Green
- Wavelength:525nm (520nm ~ 530nm)
- Current - Test:350mA
- Voltage - Forward (Vf) (Typ):3.4V
- Lumens/Watt @ Current - Test:71 lm/W
- Current - Max:500mA
- Luminous Flux @ Current/Temperature:84lm (81lm ~ 87lm)
- Temperature - Test:25°C
- Viewing Angle:125°
- Mounting Type:Surface Mount
- Package / Case:1414 (3535 Metric)
- Supplier Device Package:SMD
- Size / Dimension:0.136" L x 0.136" W (3.45mm x 3.45mm)
- Height - Seated (Max):0.084" (2.13mm)
