XQERDO-02-0000-000000903

Technical Details

• Series:XLamp® XQ-E
• Package:Tape & Reel (TR)
• Part Status:Active
• Color:Red-Orange
• Wavelength:618nm (615nm ~ 620nm)
• Current - Test:350mA
• Voltage - Forward (Vf) (Typ):2.2V
• Lumens/Watt @ Current - Test:109 lm/W
• Current - Max:1A

• Luminous Flux @ Current/Temperature:84lm (81lm ~ 87lm)
• Temperature - Test:25°C
• Viewing Angle:130°
• Mounting Type:Surface Mount
• Package / Case:0606 (1616 Metric)
• Supplier Device Package:SMD
• Size / Dimension:0.063" L x 0.063" W (1.60mm x 1.60mm)
• Height - Seated (Max):0.068" (1.73mm)
