LZ7-04MU00-0000

Technical Details

• Series:LuxiGen™
• Package:Tape & Reel (TR)
• Part Status:Active
• Color:Amber, Blue, Cyan, Green, Red, Violet, White - Cool
• Wavelength:457nm Blue, 500nm Cyan, 525nm Green, 624nm Red, 395nm Violet, 6500K White
• Current - Test:700mA Amber, 700mA Blue, 700mA Cyan, 700mA Green, 700mA Red, 700mA Violet, 700mA White
• Voltage - Forward (Vf) (Typ):3.3V Amber, 3.3V Blue, 3.45V Cyan, 3.7V Green, 2.5V Red, 3.7V Violet, 3.3V White
• Lumens/Watt @ Current - Test:42 lm/W Amber, 10 lm/W Blue, 42 lm/W Cyan, 51 lm/W Green, 47 lm/W Red, 90 lm/W White
• Current - Max:1A Amber, 1.5A Blue, 1A Cyan, 1.5A Green, 1.5A Red, 1A Violet, 1.5A White

• Luminous Flux @ Current/Temperature:96lm Amber, 24lm Blue, 101lm Cyan, 133lm Green, 83lm Red, 900mW Violet, 208lm White
• Temperature - Test:25°C
• Viewing Angle:120°
• Mounting Type:Surface Mount
• Package / Case:2828 (7070 Metric)
• Supplier Device Package:SMD
• Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
• Height - Seated (Max):0.044" (1.11mm)
