3130-1-00-21-00-00-08-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC .025DIA GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$0.43136
Quote It
Technical Details
- Series:3130
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.025" (0.64mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.179" (4.55mm)
- Length - Below Flange:0.051" (1.30mm)
- Length - Overall:0.251" (6.38mm)
- Flange Diameter:0.062" (1.57mm)
- Mounting Hole Diameter:0.052" (1.32mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.031" (0.79mm)
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:20.0µin (0.51µm)
