6585-0-00-80-00-00-03-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 6585-0-00-80-00-00-03-0 Datasheet
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$0.45648
- 1,000$0.45648
Quote It
Technical Details
- Series:6585
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Double End
- Pin Size - Above Flange:0.020" (0.51mm) Dia
- Pin Size - Below Flange:0.020" (0.51mm) Dia
- Length - Above Flange:0.125" (3.18mm)
- Length - Below Flange:0.190" (4.83mm)
- Length - Overall:0.335" (8.51mm)
- Flange Diameter:0.071" (1.80mm)
- Mounting Hole Diameter:0.057" (1.45mm)
- Mounting Type:Through Hole
- Termination:Press-Fit
- Insulation:Non-Insulated
- Board Thickness:-
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Contact Finish Thickness:200.0µin (5.08µm)
