3141-1-00-21-00-00-08-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC .040DIA GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$0.48944
Quote It
Technical Details
- Series:3141
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.040" (1.02mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.230" (5.84mm)
- Length - Below Flange:0.051" (1.30mm)
- Length - Overall:0.301" (7.65mm)
- Flange Diameter:0.070" (1.77mm)
- Mounting Hole Diameter:0.043" (1.09mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.031" (0.79mm)
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:20.0µin (0.51µm)
