2520-4-01-80-00-00-07-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 2520-4-01-80-00-00-07-0 Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$0.49536
- 1,000$0.49376
Quote It
Technical Details
- Series:2520
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End, Slotted
- Pin Size - Above Flange:0.125" (3.18mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.156" (3.96mm)
- Length - Below Flange:0.156" (3.96mm)
- Length - Overall:0.312" (7.92mm)
- Flange Diameter:0.125" (3.18mm)
- Mounting Hole Diameter:0.064" (1.63mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.125" (3.18mm)
- Contact Material:Brass Alloy
- Contact Finish:Tin
- Contact Finish Thickness:200.0µin (5.08µm)
