1067-1-00-21-00-00-03-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC 0.018DIA GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 1067-1-00-21-00-00-03-0 Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$0.5016
- 1,000$0.48592
Quote It
Technical Details
- Series:1067
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.018" (0.46mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.340" (8.64mm)
- Length - Below Flange:-
- Length - Overall:0.371" (9.42mm)
- Flange Diameter:0.072" (1.83mm)
- Mounting Hole Diameter:0.055" (1.40mm)
- Mounting Type:Through Hole
- Termination:Press-Fit, Knurled
- Insulation:Non-Insulated
- Board Thickness:-
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:20.0µin (0.51µm)
