3135-1-00-34-00-00-08-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC 0.020DIA GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 3135-1-00-34-00-00-08-0 Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
- 1$0.51056
- 1,000$0.49216
Quote It
Technical Details
- Series:3135
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.020" (0.51mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.075" (1.91mm)
- Length - Below Flange:0.051" (1.30mm)
- Length - Overall:0.176" (4.47mm)
- Flange Diameter:0.051" (1.30mm)
- Mounting Hole Diameter:0.040" (1.02mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.031" (0.79mm)
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:50.0µin (1.27µm)
