2314-1-01-44-00-00-07-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC 0.093DIA SILVER
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 2314-1-01-44-00-00-07-0 Datasheet
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$0.53296
- 1,000$0.4808
Quote It
Technical Details
- Series:2314
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End, Slotted
- Pin Size - Above Flange:0.093" (2.36mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.156" (3.96mm)
- Length - Below Flange:0.045" (1.14mm)
- Length - Overall:0.201" (5.11mm)
- Flange Diameter:0.093" (2.36mm)
- Mounting Hole Diameter:0.076" (1.93mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.031" (0.79mm)
- Contact Material:Brass Alloy
- Contact Finish:Silver
- Contact Finish Thickness:300.0µin (7.62µm)
