4366-0-00-34-00-00-03-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC .020DIA GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$0.57024
Quote It
Technical Details
- Series:4366
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.020" (0.51mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.278" (7.06mm)
- Length - Below Flange:-
- Length - Overall:0.300" (7.62mm)
- Flange Diameter:0.038" (0.97mm)
- Mounting Hole Diameter:0.034" (0.86mm)
- Mounting Type:Through Hole
- Termination:Press-Fit, Hex
- Insulation:Non-Insulated
- Board Thickness:-
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:50.0µin (1.27µm)
