2103-4-01-44-00-00-07-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC 0.062DIA SILVER
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 2103-4-01-44-00-00-07-0 Datasheet
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$0.64192
- 1,000$0.60304
Quote It
Technical Details
- Series:2103
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End, Slotted
- Pin Size - Above Flange:0.062" (1.57mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.125" (3.18mm)
- Length - Below Flange:0.149" (3.78mm)
- Length - Overall:0.305" (7.75mm)
- Flange Diameter:0.062" (1.57mm)
- Mounting Hole Diameter:0.052" (1.32mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:-
- Contact Material:Brass Alloy
- Contact Finish:Silver
- Contact Finish Thickness:300.0µin (7.62µm)
