SI88643EC-IS
Silicon Labs
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDGTL ISO 5000VRMS 4CH GP 24SOIC
- CategoryDigital Isolators
- Datasheet SI88643EC-IS Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$5.25217
- 46$4.955
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Technology:Capacitive Coupling
- Type:General Purpose
- Isolated Power:No
- Number of Channels:4
- Inputs - Side 1/Side 2:1/3
- Channel Type:Unidirectional
- Voltage - Isolation:5000Vrms
- Common Mode Transient Immunity (Min):40kV/µs
- Data Rate:100Mbps
- Propagation Delay tpLH / tpHL (Max):18ns, 23ns
- Pulse Width Distortion (Max):7ns
- Rise / Fall Time (Typ):2.5ns, 2.5ns
- Voltage - Supply:3V ~ 5.5V
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:24-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:24-SOIC
