ISO7830FDWWR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDGTL ISO 5700VRMS 3CH GP 16SOIC
- CategoryDigital Isolators
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$5.43208
- 1,000$5.3217
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Technology:Capacitive Coupling
- Type:General Purpose
- Isolated Power:No
- Number of Channels:3
- Inputs - Side 1/Side 2:3/0
- Channel Type:Unidirectional
- Voltage - Isolation:5700Vrms
- Common Mode Transient Immunity (Min):100kV/µs
- Data Rate:100Mbps
- Propagation Delay tpLH / tpHL (Max):16ns, 16ns
- Pulse Width Distortion (Max):4.1ns
- Rise / Fall Time (Typ):1.7ns, 1.9ns
- Voltage - Supply:2.25V ~ 5.5V
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.551", 14.00mm Width)
- Supplier Device Package:16-SOIC
