ADUM4150BRIZ-RL
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDGT ISOL 5000VRMS 6CH SPI 20SOIC
- CategoryDigital Isolators
- Datasheet ADUM4150BRIZ-RL Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$7.215
- 1,000$7.215
Quote It
Technical Details
- Series:iCoupler®, SPIsolator™
- Package:Tape & Reel (TR)
- Part Status:Active
- Technology:Magnetic Coupling
- Type:SPI
- Isolated Power:No
- Number of Channels:6
- Inputs - Side 1/Side 2:4/2
- Channel Type:Unidirectional
- Voltage - Isolation:5000Vrms
- Common Mode Transient Immunity (Min):25kV/µs
- Data Rate:40Mbps
- Propagation Delay tpLH / tpHL (Max):13ns, 13ns
- Pulse Width Distortion (Max):2ns
- Rise / Fall Time (Typ):2.5ns, 2.5ns
- Voltage - Supply:3V ~ 5.5V
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:20-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:20-SOIC-IC
