HCPL-901J
Broadcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDGTL ISO 2500VRMS 4CH GP 16SO
- CategoryDigital Isolators
- Datasheet HCPL-901J Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$10.97525
- 50$8.99748
- 100$8.11964
- 500$6.80293
- 1,000$5.92513
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Technology:GMR (Giant Magnetoresistive)
- Type:General Purpose
- Isolated Power:No
- Number of Channels:4
- Inputs - Side 1/Side 2:2/2
- Channel Type:Unidirectional
- Voltage - Isolation:2500Vrms
- Common Mode Transient Immunity (Min):15kV/µs
- Data Rate:110MBd
- Propagation Delay tpLH / tpHL (Max):15ns, 15ns
- Pulse Width Distortion (Max):3ns
- Rise / Fall Time (Typ):1ns, 1ns
- Voltage - Supply:3V ~ 5.5V
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:16-SO W
