ADM2483BRW
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDGT ISO 2.5KV RS422/RS485 16SOIC
- CategoryDigital Isolators
- Datasheet ADM2483BRW Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:iCoupler®
- Package:Tube
- Part Status:Last Time Buy
- Technology:Magnetic Coupling
- Type:RS422, RS485
- Isolated Power:No
- Number of Channels:3
- Inputs - Side 1/Side 2:2/1
- Channel Type:Bidirectional
- Voltage - Isolation:2500Vrms
- Common Mode Transient Immunity (Min):25kV/µs
- Data Rate:500kbps
- Propagation Delay tpLH / tpHL (Max):-
- Pulse Width Distortion (Max):-
- Rise / Fall Time (Typ):600ns, 600ns (Max)
- Voltage - Supply:3V, 5V
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:16-SOIC
