SI8422AB-B-IS

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Technology:Capacitive Coupling
• Type:General Purpose
• Isolated Power:No
• Number of Channels:2
• Inputs - Side 1/Side 2:1/1
• Channel Type:Unidirectional
• Voltage - Isolation:2500Vrms

• Common Mode Transient Immunity (Min):20kV/µs
• Data Rate:1Mbps
• Propagation Delay tpLH / tpHL (Max):35ns, 35ns
• Pulse Width Distortion (Max):25ns
• Rise / Fall Time (Typ):2ns, 2ns
• Voltage - Supply:2.7V ~ 5.5V
• Operating Temperature:-40°C ~ 125°C
• Mounting Type:Surface Mount
• Package / Case:8-SOIC (0.154", 3.90mm Width)
• Supplier Device Package:8-SOIC
