S2SRP

Technical Details

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Voltage - Off State:200 V
• Voltage - Gate Trigger (Vgt) (Max):800 mV
• Current - Gate Trigger (Igt) (Max):200 µA
• Voltage - On State (Vtm) (Max):1.7 V
• Current - On State (It (AV)) (Max):510 mA
• Current - On State (It (RMS)) (Max):800 mA

• Current - Hold (Ih) (Max):5 mA
• Current - Off State (Max):1 µA
• Current - Non Rep. Surge 50, 60Hz (Itsm):16A, 20A
• SCR Type:Sensitive Gate
• Operating Temperature:-40°C ~ 110°C
• Mounting Type:Surface Mount
• Package / Case:DO-214AA, SMB (3 Leads), Compak
• Supplier Device Package:DO-214 (Compak)
