S8015L

Technical Details

• Series:-
• Package:Bulk
• Part Status:Discontinued at Digi-Key
• Voltage - Off State:800 V
• Voltage - Gate Trigger (Vgt) (Max):1.5 V
• Current - Gate Trigger (Igt) (Max):30 mA
• Voltage - On State (Vtm) (Max):1.6 V
• Current - On State (It (AV)) (Max):9.5 A
• Current - On State (It (RMS)) (Max):15 A

• Current - Hold (Ih) (Max):40 mA
• Current - Off State (Max):20 µA
• Current - Non Rep. Surge 50, 60Hz (Itsm):188A, 225A
• SCR Type:Standard Recovery
• Operating Temperature:-40°C ~ 125°C
• Mounting Type:Through Hole
• Package / Case:TO-220-3 Isolated Tab
• Supplier Device Package:TO-220 Isolated Tab
