S2004DS2TP

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Voltage - Off State:200 V
• Voltage - Gate Trigger (Vgt) (Max):800 mV
• Current - Gate Trigger (Igt) (Max):200 µA
• Voltage - On State (Vtm) (Max):1.6 V
• Current - On State (It (AV)) (Max):2.5 A
• Current - On State (It (RMS)) (Max):4 A

• Current - Hold (Ih) (Max):6 mA
• Current - Off State (Max):2 µA
• Current - Non Rep. Surge 50, 60Hz (Itsm):25A, 30A
• SCR Type:Sensitive Gate
• Operating Temperature:-40°C ~ 110°C
• Mounting Type:Surface Mount
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
• Supplier Device Package:TO-252, (D-Pak)
