MCR22-6RLRP

Technical Details

• Series:-
• Package:Tape & Box (TB)
• Part Status:Obsolete
• Voltage - Off State:400 V
• Voltage - Gate Trigger (Vgt) (Max):800 mV
• Current - Gate Trigger (Igt) (Max):200 µA
• Voltage - On State (Vtm) (Max):1.7 V
• Current - On State (It (AV)) (Max):-
• Current - On State (It (RMS)) (Max):1.5 A

• Current - Hold (Ih) (Max):5 mA
• Current - Off State (Max):10 µA
• Current - Non Rep. Surge 50, 60Hz (Itsm):15A @ 60Hz
• SCR Type:Sensitive Gate
• Operating Temperature:-40°C ~ 110°C
• Mounting Type:Through Hole
• Package / Case:TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
• Supplier Device Package:TO-92-3
