RM6S/ILP-3F36
FERROXCUBE- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRM CORES 2PC SET
- CategoryFerrite Cores
- Datasheet RM6S/ILP-3F36 Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$0.45136
- 500$0.45136
Quote It
Technical Details
- Series:*
- Package:Bulk
- Part Status:Active
- Core Type:RM
- Supplier Device Package:RM 6
- Material:3F36
- Diameter:-
- Inductance Factor (Al):-
- Tolerance:±25%
- Gap:Ungapped
- Effective Permeability (µe):-
- Initial Permeability (µi):-
- Core Factor (ΣI/A) mm-1:0.58
- Effective Length (le) mm:21.8
- Effective Area (Ae) mm²:37.5
- Minimum Core Cross Section (Amin) mm²:31.2
- Effective Magnetic Volume (Ve) mm³:820
- Finish:Uncoated
- Height:9.00mm
- Length:17.90mm
- Width:8.20mm
