B65855B0000Y038
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFERRITE CORE EP 1.9UH T38 2PCS
- CategoryFerrite Cores
- Datasheet B65855B0000Y038 Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$0.57363
- 42,000$0.553
Quote It
Technical Details
- Series:B65855B
- Package:Box
- Part Status:Active
- Core Type:EP
- Supplier Device Package:EP 6
- Material:T38
- Diameter:-
- Inductance Factor (Al):1.9 µH
- Tolerance:-30%, +40%
- Gap:Ungapped
- Effective Permeability (µe):5100
- Initial Permeability (µi):2300
- Core Factor (ΣI/A) mm-1:3.35
- Effective Length (le) mm:10.28
- Effective Area (Ae) mm²:3.06
- Minimum Core Cross Section (Amin) mm²:2.3
- Effective Magnetic Volume (Ve) mm³:31
- Finish:Uncoated
- Height:3.05mm
- Length:6.15mm
- Width:3.90mm
Related Products
EP AND EPX CORES 2PC SET
