B59870C0080A051

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Ceramic
• Voltage - Max:265V
• Current - Max:1 A
• Current - Hold (Ih) (Max):60 mA
• Current - Trip (It):130 mA
• Time to Trip:-
• Resistance - Initial (Ri) (Min):-

• Resistance - Post Trip (R1) (Max):-
• Resistance - 25°C (Typ):25 Ohms
• Operating Temperature:0°C ~ 60°C
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.354" Dia x 0.197" T (9.00mm x 5.00mm)
• Height - Seated (Max):0.492" (12.50mm)
• Thickness (Max):-
• Lead Spacing:0.197" (5.00mm)
