RXE020

Technical Details

• Series:PolySwitch®, RXE
• Package:Bulk
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:72V
• Current - Max:40 A
• Current - Hold (Ih) (Max):200 mA
• Current - Trip (It):400 mA
• Time to Trip:2.2 s
• Resistance - Initial (Ri) (Min):1.83 Ohms

• Resistance - Post Trip (R1) (Max):4.4 Ohms
• Resistance - 25°C (Typ):-
• Operating Temperature:-
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.291" Dia x 0.118" T (7.40mm x 3.00mm)
• Height - Seated (Max):0.461" (11.70mm)
• Thickness (Max):-
• Lead Spacing:0.199" (5.05mm)
