MF-RX185

Technical Details

• Series:Multifuse®, MF-RX
• Package:Bulk
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:60V
• Current - Max:40 A
• Current - Hold (Ih) (Max):1.85 A
• Current - Trip (It):3.7 A
• Time to Trip:12.6 s
• Resistance - Initial (Ri) (Min):80 mOhms

• Resistance - Post Trip (R1) (Max):190 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.701" L x 0.122" W (17.80mm x 3.10mm)
• Height - Seated (Max):0.902" (22.90mm)
• Thickness (Max):-
• Lead Spacing:0.201" (5.10mm)
