MF-MSMD150-2

Technical Details

• Series:Multifuse®, MF-MSMD
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:6V
• Current - Max:100 A
• Current - Hold (Ih) (Max):1.5 A
• Current - Trip (It):3 A
• Time to Trip:500 ms
• Resistance - Initial (Ri) (Min):30 mOhms

• Resistance - Post Trip (R1) (Max):120 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:-
• Mounting Type:Surface Mount
• Package / Case:1812 (4532 Metric)
• Size / Dimension:0.179" L x 0.015" W (4.55mm x 0.39mm)
• Height - Seated (Max):-
• Thickness (Max):0.134" (3.41mm)
• Lead Spacing:-
