SMD1206P020TSA
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPTC RESET FUSE 16V 200MA 1206
- CategoryPTC Resettable Fuses
- Datasheet SMD1206P020TSA Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:POLY-FUSE®, SMD1206
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Polymeric
- Voltage - Max:16V
- Current - Max:40 A
- Current - Hold (Ih) (Max):200 mA
- Current - Trip (It):400 mA
- Time to Trip:50 ms
- Resistance - Initial (Ri) (Min):600 mOhms
- Resistance - Post Trip (R1) (Max):2.5 Ohms
- Resistance - 25°C (Typ):-
- Operating Temperature:-40°C ~ 85°C
- Ratings:-
- Mounting Type:Surface Mount
- Package / Case:1206 (3216 Metric), Concave
- Size / Dimension:0.128" L x 0.065" W (3.25mm x 1.65mm)
- Height - Seated (Max):-
- Thickness (Max):0.030" (0.75mm)
- Lead Spacing:-
