AGRF700S-1

Technical Details

• Series:PolySwitch®, AGRF
• Package:Bulk
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:16V
• Current - Max:100 A
• Current - Hold (Ih) (Max):7 A
• Current - Trip (It):13.2 A
• Time to Trip:4 s
• Resistance - Initial (Ri) (Min):6.6 mOhms

• Resistance - Post Trip (R1) (Max):20 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:AEC-Q200
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.441" L x 0.118" W (11.20mm x 3.00mm)
• Height - Seated (Max):0.827" (21.00mm)
• Thickness (Max):-
• Lead Spacing:0.200" (5.08mm)
