VLR170U-C30F

Technical Details

• Series:PolySwitch®, VLR
• Package:Bulk
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:12V
• Current - Max:100 A
• Current - Hold (Ih) (Max):1.7 A
• Current - Trip (It):4.1 A
• Time to Trip:5 s
• Resistance - Initial (Ri) (Min):18 mOhms

• Resistance - Post Trip (R1) (Max):64 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 70°C
• Ratings:-
• Mounting Type:User Defined
• Package / Case:Strap
• Size / Dimension:0.866" L x 0.142" W (22.00mm x 3.60mm)
• Height - Seated (Max):-
• Thickness (Max):0.032" (0.80mm)
• Lead Spacing:-
