0ZCD0110FF2C

Technical Details

• Series:0ZCD
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:33V
• Current - Max:40 A
• Current - Hold (Ih) (Max):1.1 A
• Current - Trip (It):2.2 A
• Time to Trip:500 ms
• Resistance - Initial (Ri) (Min):90 mOhms

• Resistance - Post Trip (R1) (Max):410 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:-
• Mounting Type:Surface Mount
• Package / Case:2920 (7351 Metric)
• Size / Dimension:0.290" L x 0.202" W (7.36mm x 5.12mm)
• Height - Seated (Max):-
• Thickness (Max):0.039" (1.00mm)
• Lead Spacing:-
