72R300XMR

Technical Details

• Series:POLY-FUSE®, 72R
• Package:Tape & Box (TB)
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:72V
• Current - Max:40 A
• Current - Hold (Ih) (Max):3 A
• Current - Trip (It):6 A
• Time to Trip:19.8 s
• Resistance - Initial (Ri) (Min):40 mOhms

• Resistance - Post Trip (R1) (Max):100 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.910" Dia x 0.122" T (23.11mm x 3.10mm)
• Height - Seated (Max):1.154" (29.30mm)
• Thickness (Max):-
• Lead Spacing:0.402" (10.20mm)
