TRF250-183S-0.110

Technical Details

• Series:PolySwitch®, TRF250
• Package:Bag
• Part Status:Active
• Type:Polymeric
• Voltage - Max:100V (250V Int)
• Current - Max:10 A
• Current - Hold (Ih) (Max):183 mA
• Current - Trip (It):685 mA
• Time to Trip:1.8 s
• Resistance - Initial (Ri) (Min):800 mOhms

• Resistance - Post Trip (R1) (Max):3.4 Ohms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.295" Dia x 0.150" T (7.50mm x 3.80mm)
• Height - Seated (Max):0.374" (9.50mm)
• Thickness (Max):-
• Lead Spacing:0.200" (5.08mm)
