RGEF700-AP

Technical Details

• Series:PolySwitch®, RGEF
• Package:Cut Tape (CT)Tape & Box (TB)
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:16V
• Current - Max:100 A
• Current - Hold (Ih) (Max):7 A
• Current - Trip (It):11.9 A
• Time to Trip:3.5 s
• Resistance - Initial (Ri) (Min):7.7 mOhms

• Resistance - Post Trip (R1) (Max):20 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.421" L x 0.098" W (10.70mm x 2.50mm)
• Height - Seated (Max):0.776" (19.70mm)
• Thickness (Max):-
• Lead Spacing:0.199" (5.05mm)
