0669-0-15-80-30-27-10-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0669-0-15-80-30-27-10-0 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$0.61184
- 1,000$0.61184
Quote It
Technical Details
- Series:0669
- Package:Bulk
- Part Status:Active
- Tail Type:No Tail
- Termination:Solder
- Length - Overall:0.125" (3.18mm)
- Accepts Pin Diameter:0.015" ~ 0.025" (0.38mm ~ 0.64mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.043" (1.09mm)
- Mounting Hole Diameter:0.060" (1.52mm)
- Flange Diameter:0.072" (1.83mm)
- Tail Diameter:-
- Socket Depth:0.100" (2.54mm)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
