0814-0-15-80-34-80-04-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0814-0-15-80-34-80-04-0 Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$0.63536
- 1,000$0.63536
Quote It
Technical Details
- Series:0814
- Package:Bulk
- Part Status:Active
- Tail Type:Standard Tail
- Termination:Solder
- Length - Overall:0.280" (7.11mm)
- Accepts Pin Diameter:0.032" ~ 0.046" (0.81mm ~ 1.17mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.064" (1.63mm)
- Mounting Hole Diameter:0.082" (2.08mm)
- Flange Diameter:0.090" (2.29mm)
- Tail Diameter:0.030" (0.76mm)
- Socket Depth:0.150" (3.81mm)
- Contact Material:Beryllium Copper
- Contact Finish:Tin
- Contact Finish Thickness:200.0µin (5.08µm)
