0461-5-15-80-11-84-04-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0461-5-15-80-11-84-04-0 Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
- 1$0.6376
- 1,000$0.6376
Quote It
Technical Details
- Series:0461
- Package:Bulk
- Part Status:Active
- Tail Type:Standard Tail
- Termination:Solder
- Length - Overall:0.615" (15.62mm)
- Accepts Pin Diameter:0.015" ~ 0.022" (0.38mm ~ 0.56mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.031" (0.79mm)
- Mounting Hole Diameter:0.020" (0.51mm)
- Flange Diameter:0.041" (1.04mm)
- Tail Diameter:0.018" (0.46mm)
- Socket Depth:0.150" (3.81mm)
- Contact Material:Beryllium Copper
- Contact Finish:Tin
- Contact Finish Thickness:100.0µin (2.54µm)
