8898-0-15-15-30-14-04-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 8898-0-15-15-30-14-04-0 Datasheet
-
ECAD Model
- Share
In Stock: 150
Can ship immediately
Pricing:
- 1$0.64992
- 1,000$0.64
Quote It
Technical Details
- Series:8898
- Package:Bulk
- Part Status:Active
- Tail Type:Standard Tail
- Termination:Press-Fit
- Length - Overall:0.376" (9.55mm)
- Accepts Pin Diameter:0.015" ~ 0.025" (0.38mm ~ 0.64mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.043" (1.09mm)
- Mounting Hole Diameter:0.057" (1.45mm)
- Flange Diameter:0.072" (1.83mm)
- Tail Diameter:0.020" (0.51mm)
- Socket Depth:0.146" (3.71mm)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:10.0µin (0.25µm)
