0279-0-15-01-47-01-10-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT .025-.037 HEX
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0279-0-15-01-47-01-10-0 Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$0.65136
- 1,000$0.64992
Quote It
Technical Details
- Series:279
- Package:Bulk
- Part Status:Active
- Tail Type:No Tail
- Termination:Press-Fit, Hex
- Length - Overall:0.200" (5.08mm)
- Accepts Pin Diameter:0.025" ~ 0.037" (0.64mm ~ 0.94mm)
- Accepts Square Pin Size:0.025" (0.64mm)
- Pin Hole Diameter:0.051" (1.30mm)
- Mounting Hole Diameter:0.062" (1.57mm)
- Flange Diameter:0.078" (1.98mm)
- Tail Diameter:-
- Socket Depth:0.165" (4.19mm)
- Contact Material:Beryllium Copper
- Contact Finish:Tin-Lead
- Contact Finish Thickness:200.0µin (5.08µm)
