4994-0-15-15-11-14-10-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 4994-0-15-15-11-14-10-0 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$0.6792
- 1,000$0.67136
Quote It
Technical Details
- Series:4994
- Package:Bulk
- Part Status:Active
- Tail Type:No Tail
- Termination:Press-Fit
- Length - Overall:0.155" (3.94mm)
- Accepts Pin Diameter:0.015" ~ 0.020" (0.38mm ~ 0.51mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.107" (2.72mm)
- Mounting Hole Diameter:-
- Flange Diameter:0.055" (1.40mm)
- Tail Diameter:-
- Socket Depth:0.100" (2.54mm)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:10.0µin (0.25µm)
