0415-0-15-01-16-27-10-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT .022-.034 SOLDER
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0415-0-15-01-16-27-10-0 Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$0.6832
- 1,000$0.36449
Quote It
Technical Details
- Series:415
- Package:Bulk
- Part Status:Active
- Tail Type:No Tail
- Termination:Solder
- Length - Overall:0.190" (4.83mm)
- Accepts Pin Diameter:0.022" ~ 0.034" (0.56mm ~ 0.86mm)
- Accepts Square Pin Size:0.025" (0.64mm)
- Pin Hole Diameter:0.051" (1.30mm)
- Mounting Hole Diameter:0.063" (1.60mm)
- Flange Diameter:0.078" (1.98mm)
- Tail Diameter:-
- Socket Depth:0.165" (4.19mm)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
