0086-4-17-01-30-27-02-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT .015-.025 PRESSFIT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0086-4-17-01-30-27-02-0 Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$0.70272
- 1,000$0.69408
Quote It
Technical Details
- Series:86
- Package:Bulk
- Part Status:Active
- Tail Type:Wire Wrap
- Termination:Press-Fit
- Length - Overall:0.823" (20.90mm)
- Accepts Pin Diameter:0.015" ~ 0.025" (0.38mm ~ 0.64mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.043" (1.09mm)
- Mounting Hole Diameter:0.057" (1.45mm)
- Flange Diameter:0.071" (1.80mm)
- Tail Diameter:0.025" (0.64mm) Square
- Socket Depth:0.162" (4.12mm)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
