714-83-109-31-012101
Preci-Dip
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT .016-.021 SOLDER
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 714-83-109-31-012101 Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$0.71072
- 1,000$0.63411
Quote It
Technical Details
- Series:714
- Package:Strip
- Part Status:Active
- Tail Type:No Tail
- Termination:Solder
- Length - Overall:0.136" (3.45mm)
- Accepts Pin Diameter:0.016" ~ 0.021" (0.41mm ~ 0.53mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:-
- Mounting Hole Diameter:0.039" ~ 0.051" (0.99mm ~ 1.30mm)
- Flange Diameter:0.055" (1.40mm)
- Tail Diameter:-
- Socket Depth:0.124" (3.15mm)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
