0323-4-15-01-34-01-10-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT .032-.046 SWAGE
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0323-4-15-01-34-01-10-0 Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$0.7521
- 1,000$0.7521
Quote It
Technical Details
- Series:323
- Package:Bulk
- Part Status:Active
- Tail Type:Turret
- Termination:Swage
- Length - Overall:0.454" (11.53mm)
- Accepts Pin Diameter:0.032" ~ 0.046" (0.81mm ~ 1.17mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.064" (1.63mm)
- Mounting Hole Diameter:0.094" (2.39mm)
- Flange Diameter:0.125" (3.18mm)
- Tail Diameter:-
- Socket Depth:0.200" (5.08mm)
- Contact Material:Beryllium Copper
- Contact Finish:Tin-Lead
- Contact Finish Thickness:200.0µin (5.08µm)
